OTOFIX D1 Lite vs. D1 vs. D1 Pro vs. D1 MAX Comparison

What's different between OTOFIX D1 Lite, D1, D1 Pro and D1 MAX diagnostic scan tool? Here we've listed all details including price, hardware, software and expansibility for comparison.



Autel OTOFIX Comparison

Model	OTOFIX D1 LITE	OTOFIX D1	OTOFIX D1 PRO	OTOFIX D1 MAX
Price	€309	€429	€669	€856
Release time	2021	2021	2022	2022
RAM	2GB	2GB	4GB	4GB
ROM	64GB	64GB	128GB	128GB
Battery capacity	5800mAh	5800mAh	15000mAh	7250mAh
Android version	Android 9.0	Android 9.0	Android 10.0	Android 11.0
Screen size	7 inch	7 inch	10.1 inch	10.4 inch
Screen resolution	1280*800	1280*800	1920*1200	2000*1200
Camera	Rear 8M	Rear 8M	Rear 16M	Front 5M Rear 8M
Weight	463g(1.02 lb.)	463g(1.02 lb.)	1200g(2.2 lb.)	760g(1.68lb.)
VCI	V1	V1	V1	V1
Read/clear codes	√	√	√	√
Read live data	√	√	√	√
Read freeze frame	√	√	√	√
ECU info	√	√	√	√
Service	√	√	√	√
Special function	√ (Latest version)	√	√	√
Active test	√ (Latest version)	√	√	√
BMW online ECU coding	×	×	Only support in Chinese Traditional system	√
MINI online ECU coding	×	×	Only support in Chinese Traditional system	√
Audi online ECU coding	×	√	√	√
Porsche online ECU coding	×	×	×	√
VW online ECU coding	×	√	√	√
VW_Brazil online ECU function	×	√	√	√
Skoda online ECU function	×	√	√	√
Peugeot online ECU function	×	×	√	√
Citroen online ECU function	×	×	√	√
DS online ECU function	×	×	√	√
Nissan online ECU function	×	×	×	√
Nissan-GTR online ECU function	×	×	×	√
Infiniti online ECU function	×	×	×	√
Renault online ECU function	×	×	×	√
BMW hidden feature	×	×	Only support in Chinese Traditional system	√
MINI hidden feature	×	×	Only support in Chinese Traditional system	√
VW, Audi, Skoda hidden feature	×	√	√	√
VW, Audi, Skoda, Seat guided function	×	√	√	√
MaxiVideo (work with MV105/MV108S)	×	√ (need Flash cable)	√	√ (need Flash cable)
Battery test (work with BT1 Lite)	√ (optional)	√ (optional)	√ (optional)	√ (optional)
Report management	√	√	√	√
Language	Muti-language	Muti-language	Muti-language	Muti-language
Auto VIN	√	√	√	√
SCAN VIN/License	√	√	√	√
Remote desk	√	√	√	√
DoIP/CAN FD	√	√	√	√
Pre&Post scan	×	×	√	√
WiFi print	×	×	√	√
Renault security gateway function	√ (Renault V2.0 or above)	√ (Renault V2.0 or above)	√ (Renault V2.0 or above)	√ (Renault V2.0 or above)



Difference

1. Price

OTOFIX D1 Lite < D1 < D1 Pro < D1 MAX

- D1 Lite is the cheapest while D1 MAX is the most expensive.



2. Hardware

OTOFIX D1 Lite < D1 < D1 Pro < D1 MAX

- D1 MAX is equipped with the highest hardware configuration.

- D1 Pro has the largest battery capability.



3. Software

OTOFIX D1 Lite < D1 < D1 Pro < D1 MAX

- D1 MAX supports more diagnostic functions than other models such as online ECU coding, hidden features, guided function, etc.

- OTOFIX D1 Lite is the entry level diagnostic tool to support full system diagnosis, read/clear codes, live data, check ECU info, freeze frame, active test, service and special functions.



4. Extensible Function

OTOFIX D1 Lite < D1 < D1 Pro = D1 MAX

- D1 MAX has the highest compatibility to support endoscope, test battery, Pre&Post scan, WiFi print, etc.



Conclusion

If you're a beginner, the entry-level OTOFIX D1 Lite should be a good choice.

If you'd like a most comprehensive and advanced tool, D1 MAX is worth the investment.

Or you may choose other models according to actual needs and budget, which will never go wrong.
